2025 Yamaha Outboards Midrange 30 hp Base

Description

2025 Yamaha Outboards Midrange 30 hp

Everyone’s perfect day on the water looks a little different. So, whether you’re teaching the grandkids to fish, heading to a bash on the sandbar or cruising the lake on your pontoon, count on Yamaha’s Midrange 40 and 30 hp outboards to bring the fun. Compact and powerful, they’re perfect for light duty on skiffs, jon boats, inflatables and small pontoons or aluminum fishing boats. Whatever you’re up to, get out there with Yamaha’s Midrange 40 and 30 hp outboards.

Our 747-cc 30-hp midrange boasts a streamlined design and solid performance. At just 214 pounds, it’s suitable for lightweight craft such as aluminum fishing boats and inflatables. Its Nitro Assist Tilt makes tilting almost effortless.

Features may include:
  • Available for mechanical or tiller-handle control
  • Only 214 pounds
  • Available in a 20” shaft
  • Powerful 17-amp alternator
  • Power and Performance

    Fuel Economy

    Precision Multi-Point Electronic Fuel Injection delivers the exact amount of fuel needed for optimum performance and efficiency. Yamaha’s EFI optimizes fuel atomization further enhancing fuel economy.

    Single Overhead Camshaft

    A Single Overhead Camshaft (SOHC), three-cylinder design on the F40 and F30 provides a compact, lightweight, space-saving design.

    Precise Throttle Control

    All air entering the engine block is routed through a single throttle valve, to ensure the precise amount of air necessary for optimum power and fuel efficiency. It then enters each cylinder through individual long intake tracks, which are 'pulse tuned' to provide air at the precise volume and timing for maximum density and power.

    Convenience and Control

    CONTROL AND COMFORT

    Our optional, award-winning Multi-Function Tiller handle features a Variable Trolling RPM Switch (VTS®). It allows for precision trolling speed adjustments in 50-RPM increments. Compatible with all Midrange models.

    EASY ENGINE FLUSHING

    A Freshwater Flush Device allows you to flush the engine without running it, for added convenience and extended engine life.

    POWER TRIM AND TILT

    Power trim and tilt models provide a trim range of -3 up to +20 degrees. This brings the bow of the boat up, for better hole shot and top speed and a smoother ride.

    Specifications

    ManufacturerYamaha Outboards
    ModelMidrange 30 hp
    Year2025
    ConditionNew
    Trim NameBase
    Generic Type (Primary)Four Stroke
    Engine Type3 cyl
    Engine PowerProp Shaft: 30hp at 5500rpm
    Displacement747cc
    Bore2.56 in (65 mm)
    Stroke2.95 in (75 mm)
    Compression Ratio9.4:1
    ThrottleFull RPM Range: 5000 ~ 6000 rpm
    SteeringAngle (maximum): 40° from center, either direction
    ExhaustThrough Propeller
    IgnitionCDI Microcomputer
    Oil TypeRecommended: Yamalube® 4M (See owner's manual)
    LubricationWet Sump
    CoolingRecommended: Thermostatic Control
    Gear Ratio (Primary)2.00:1
    Gear ShifterForward, Neutral, Reverse
    InductionEFI
    Spark PlugDPR6EB-9
    StarterSystem: Electric
    Alternator Output, MaximumOutput at W.O.T.: 17 Amp
    Fuel SystemEthanol Blend Limit: 10% Maximum
    Fuel TypeRecommended: Octane 87 | Recommended Filtration: Yamaha 10-Micron Fuel/Water Separating Filter (external)
    LengthShaft: 20"
    DimensionsDegree of Tilt: 65° - 66° | Degree of Trim: -3° through +20°
    Oil capacity1.7L/1.5L
    Weight214 lbs (97 kg) - 223 lbs (101 kg)
    FeaturesIntake: 6
    WarrantyLimited 3-year Pleasure, 3-year Government, 1-Year Commercial
